Apollo UV96T40, UV Printer


The new APOLLO UV UV96T40 has a 35” x 24” (90 x 60cm) printing area, that allow you to print in different rigid materials with a low cost, it brings the versatility of printing with white and varnish option and also has anti-collision system to protect the printheads and anti-static media system for a better printing quality.

Indroducing New Apollo UV96T40

  • Feature Icon
    up to
    4800
    dpi
  • Feature Icon
    up to
    6
    printheads
  • Feature Icon
    up to
    129
    sq.ft/h

The new APOLLO UV UV96T40 has a 35” x 24” (90 x 60cm) printing area, that allow you to print in different rigid materials with a low cost, it brings the versatility of printing with white and varnish option and also has anti-collision system to protect the printheads and anti-static media system for a better printing quality.

Easy to operate and low maintenance equipment, the APOLLO UV UV96T40 will surely become a new source of profitability for your company and a much faster return on investment than any other competitor.

Toshiba Ce4M Printhead

Up to 8 Toshiba CE4M Pritheads | 636 nozzles

GALAXY UV96T40
Printhead Toshiba CE4M • 636 nozzles • Variable dots • 5/10/15 pl
Number of Printheads 4 / 5 or 6
Resolution Up to 4,800 dpi
Ink UV | CMYK, CMYK + W, CMYK + W + V
Max. printing width 23″ x 35″ (600 x 900 mm)
Auto feeding / Take-up System Vaccum Table
Media PS Board, Tile, Wood, PVC Foam Board, Acrylic, Aluminum, Glass and most of rigid materials.
Print Speed Draft (6 passes): 129 sq.ft./h (12 m²/h)
Standard (8 passes): 86 sq.ft./h (8 m²/h)
Quality (12 passes): 64 sq.ft./h (6 m²/h)
High Quality (16 passes): 43 sq.ft./h (4 m²/h)
Cleaning System Negative Pressure Ink Control System
Max. Carriage Height 5.9″(150 mm)
RIP Software PhotoPrint OEM or MainTop RIP. FlexiPrint 12 Optional
Voltage AC 220 V • 50 / 60 Hz
Interface USB 3.0
Operating Temperature Temperature 20ºC – 28ºC (68ºF – 82ºF) Humidity 40% – 60% – no-condensing
Equipment dimensions 74” x 69” x 57”
(1,880 x 1,770 x 1,460 mm)
Package dimensions 79” x 78” x 66”
(2,000 x 1,980 x 1,670 mm)
Equipment weight Net: 648 lbs (294 kg) • Gross: 1,141 lbs (518 kg)
